EPCOM POWERLINE
Carrete de 500 Metros / Cable Fotovoltaico Negro / 6mm² (10AWG) / Material COBRE / 2000 Vcc
Carrete de 500 Metros / Cable Fotovoltaico Negro / 6mm² (10AWG) / Material COBRE / 2000 Vcc
Couldn't load pickup availability
CBLPV10B / 500
Carrete de 500 m Cable Fotovoltaico Negro / 6mm² (10AWG)
Cobre Tipo PV, 1000 / 2000 V 120 °C.
Cable formado por un conductor flexible de cobre suave, con aislamiento de polietileno de cadena cruzada XLPE
Características
- El conductor es cobre suave en cableado
- Alta resistencia a los rayos UV, al ozono y a la hidrolización.
- Resistencia a altas temperaturas
- Flexibilidad en condiciones de frío
- Vida útil esperada de más de 25 años
Características Físicas y Eléctricas
- Material: Cobre desnudo
- Tipo: PV
- Tamaño: 6 mm²
- Calibre: 10 AWG
- Construcción del conductor: 76 X 0.30 mm
- Diámetro del conductor externo: 6.82 mm
- Tensión máxima de operación: 1000 / 2000 V
- Color externo: Negro
- Temperatura de operación: -40°C a 120 °C
- Estándares:
- Rendimiento a prueba de fuego: IEC602332-1; IEC602332-24
- Emisión de humo: IEC61034, EN61034-2
- Baja carga de fuego: DIN 51900
- Aprobación: UL 4703
Modelos Relacionados
- 6 mm² (10 AWG):
- CBLPV10R/25. 25M / Rojo / 6 mm² (10 AWG)
- CBLPV10B/25. 25M / Rojo / 6 mm² (10 AWG)
- CBLPV10R/100. 100M / Rojo / 6 mm² (10 AWG)
- CBLPV10B/100. 100M / Negro / 6 mm² (10 AWG)
- CBLPV10R/500. 500M / Rojo / 6 mm² (10 AWG)
- CBLPV10B/500 500M / Negro / 6 mm² (10 AWG)
- 10 mm² (8 AWG):
- CBLPV8R/50. 50M / Rojo / 10 mm² (8 AWG)
- CBLPV8B/50. 50M / Negro / 10 mm² (8 AWG)
- 16 mm² (6 AWG):
- CBLPV6B/50. 50M / Negro / 16 mm² (6 AWG)
- CBLPV6R/50. 50M / Rojo / 16 mm² (6 AWG)
- CBLPV6R/100. 100M / Rojo / 16 mm² (6 AWG)
- CBLPV6B/100. 100M / Negro / 16 mm² (6 AWG)
- CBLPV6R/500. 500M / Negro / 16 mm² (6 AWG)
- CBLPV6B/500. 500M / Negro / 16 mm² (6 AWG)
- ALEACCION COBRE ESTAÑO:
- 6 mm² (10 AWG)
- CBLUT10R/100. 100M / Rojo / 6 mm² (10 AWG)
- CBLUT10B/100. 100M / Negro / 6 mm² (10 AWG)
- JUMPERS:
- 6 mm² (10 AWG)
- CFMC41MRED. MC4.M/1M / Rojo / 6 mm² (10 AWG)
- CFMC41MBLK. MC4.M/1M / Negro / 6 mm² (10 AWG)
