MEANWELL
Cargador para Baterías de Plomo Ácido y Litio / 13.5A / 12V / Bancos de 55 a 180 Ah/ Con cable de alimentación
Cargador para Baterías de Plomo Ácido y Litio / 13.5A / 12V / Bancos de 55 a 180 Ah/ Con cable de alimentación
Couldn't load pickup availability
Cargador de Baterías Para Plomo Ácido y Litio
Características
- Entrada de CA universal de 90~264 Vca, PFC incorporado
- Cargador compatible con baterías de plomo-ácido y li-ion.
- Diseño sin ventilador
- Amplio rango de salida ajustable mediante VR:
- - Voltaje de carga ajustable (10,5~15,2V)
- - Corriente de carga ajustable (50~100% de corriente nominal)
- 2 o 3 etapas seleccionables por DIP S.W
- Consumo de energía sin carga <0,15 W (AC S.W apagado)
- -30°C - +70°C amplia temperatura de funcionamiento
- Protecciones: Cortocircuito/Sobretensión/Sobretemperatura/Protección de polaridad inversa de la batería
- Cumple con la certificación dual UL/EN62368-1 y EN60335-1/2-29
- Indicador LED del panel frontal para el estado de carga
Especificaciones Técnicas
- Voltaje de Entrada: 90-264Vca 47-63 Hz
- Voltaje de Salida: 12Vcc
- Corriente de Salida: 13.5A
- Potencia de Salida: 205.2W
- Dimensiones: 182.7 x 96 x 49 mm
Aplicaciones
- Solución de respaldo del sistema de radio
- Cargador de patinete eléctrico
- Autocaravana / Autobuses / Camión pesado / Vehículos especiales
- Sistema de vigilancia
- Herramientas eléctricas portátiles
NOTA: Incluye cable de alimentación AC-CORD-1.5M
